Acer 3.0mm DC Jack with Cable for Aspire 5 / Swift 3 / Spin 5 — quick answer
The Acer 3.0mm DC Jack with Cable for Aspire 5 / Swift 3 / Spin 5 is a replacement Acer DC power jack with pre-attached cable harness available at N.N Laptops, Hafeez Center, Lahore for Rs. 1,599. It's the OEM-spec 3.0mm × 1.0mm female slim barrel female jack for Aspire 5, Swift 3, Spin 5. Plug-in installation (no soldering on the cable side), backed by our 30-day check warranty and nationwide delivery via TCS / Leopards.
Full specifications
| Brand | Acer |
|---|---|
| Connector Type | 3.0mm × 1.0mm female slim barrel |
| Cable Length | ~6-8cm pigtail with motherboard connector |
| Compatible Models | Aspire 5, Swift 3, Spin 5, Aspire 3, TravelMate P2 |
| Installation | Plug-in (no soldering on harness side) |
| Condition | Genuine — New service part |
| Warranty | 30-day check warranty |
Compatibility — which laptops does this DC jack fit?
This 3.0mm × 1.0mm female slim barrel female DC jack with pre-attached cable harness fits:
- Aspire 5 (A515-51, A515-52, A515-54)
- Swift 3 (SF314-54, SF314-55G)
- Spin 5 (SP513-52N, SP513-54N)
- Aspire 3 (A315-51, A315-53)
- TravelMate P2 (TMP259-M)
Match the connector type on your existing charger before ordering. If your laptop charges via a 3.0mm × 1.0mm female slim barrel barrel, this part is the correct fit — no other variant of jack will physically mate with the OEM charger. If you're unsure, send a photo of your old jack to WhatsApp 0314 4000131 and we'll verify.
Common DC jack failure symptoms
If any of these match your laptop, the jack is the likely culprit:
- Charger LED is on, but laptop only charges if you wiggle the cable at a specific angle
- Battery indicator on screen flickers between 'charging' and 'not charging' randomly
- You feel the jack move when you push on the charger plug
- The plug feels loose; the connection isn't snug like it used to be
- Charging suddenly cuts out when you bump the laptop
If two or more of these match, the internal jack solder pads have likely cracked from years of plug-in / plug-out stress. Replacing the harness is a permanent fix. This DC jack is a common weakness on these Acer models, and having a spare on hand can save you downtime.
Installation — step by step
Most modern laptops use a cable-harness jack like this one (rather than a board-soldered jack), so installation is screwdriver-only:
- Power off laptop, remove AC and battery
- Unscrew bottom panel (8-12 Phillips, sometimes Torx T5)
- Locate old DC jack pigtail connector on motherboard
- Unlatch ribbon / unplug 2-pin connector
- Remove old jack from chassis (1-2 screws, sometimes glued — gently pry)
- Seat new jack into the same recess, screw down
- Plug new harness into motherboard connector
- Reassemble, test with charger before fully closing
Total time: 20-30 minutes for someone comfortable with laptop teardown. We do free installation in shop if you bring the laptop to Hafeez Center. For DIY, take your time and ensure the connector is fully seated.
Build quality & why we sell this specific part
OEM-grade plastic body with proper metal contacts for the centre-pin and outer-barrel return. The wire harness uses heavier 22 AWG copper than no-name aftermarket parts — important because a Aspire 5 charger draws up to 4-6A and thinner copper would heat up under load. The motherboard-side connector is the correct keyed JST type, so it only fits one way and you can't reverse it. Every unit is quality-checked before listing.
Real-world use and buying advice
This DC jack is a popular repair item for Acer laptops that are 3-5 years old. We recommend buying one now if you notice any intermittent charging, as delaying can damage the motherboard connector. The Rs. 1,599 price is competitive for a genuine Acer part; cheaper alternatives often use thinner wire that may overheat. For customers in Lahore, Karachi, Islamabad, Rawalpindi, Faisalabad, Multan, or Peshawar, we offer same-day Lahore delivery and nationwide shipping via TCS/Leopards. Visit us at Shop 66A, 3rd Floor, Hafeez Center, Gulberg III, Lahore, or contact Sayam on WhatsApp 0314 4000131 to order or ask questions.
Where to buy in Lahore
Visit us at Shop 66A, 3rd Floor, Hafeez Center, Gulberg III, Lahore. We stock dozens of jack variants — bring your laptop or the old jack and we'll match it instantly. Lahore delivery, nationwide via TCS / Leopards. WhatsApp 0314 4000131 for stock confirmation or live photos of the exact unit. Browse our full laptop parts, laptop chargers, and laptop batteries selection.
Warranty
Every DC jack carries our 30-day check warranty. If the jack fails on install, develops loose contact within 30 days, or causes intermittent charging, return it to the shop with the invoice for a full replacement. No questions asked within the warranty window. We stand by our parts because we test them ourselves.
Frequently asked questions
How do I know if my DC jack is actually the problem?
Symptoms: laptop only charges if the plug is held at an angle; charging stops when you wiggle the cable; battery indicator flickers between charging and discharging on screen. If your charger LED is on but the laptop says 'plugged in, not charging' randomly, the jack is the likely culprit.
Is the cable harness already attached?
Yes. The jack ships with a 6-8cm wire pigtail pre-soldered to the jack and terminated with the small 2-pin or 4-pin motherboard connector — just plug it into the board, no soldering required for the harness side.
Will the charger plug feel loose or work intermittently after I install this jack?
If the new jack is seated correctly on the motherboard and the solder joints are clean, the plug should feel firm — no wobble, no flicker. A loose-feeling charger after replacement usually means a cold solder joint on one of the four mounting pads.
Does this fit the Aspire 5?
Yes — this exact jack matches the OEM part number and connector size for the Aspire 5, Swift 3, Spin 5. We've sold dozens of these to repair shops across Lahore. If you're unsure, send us a photo of your old jack on WhatsApp 0314 4000131 and we'll verify before you order.
What if the connector doesn't match my laptop?
If you mistakenly order the wrong jack, contact us within 7 days via WhatsApp 0314 4000131 with your order number. We'll guide you on the correct part or arrange a return if unused. It's best to confirm compatibility before buying.
